Best Batteries and Chargers for Light Painting Photography 2022

Updated: 10 hours ago

This is the 2022 edition of the Battery and Charger Buying Guide for Light Painting and Night Photographers. This article is now in its 6th year. An increasing number of Li-ion battery based flashlights/torches now come with high quality internal charging, and included batteries. However, I still recommend using dedicated chargers when possible. If your flashlight / torch does not come with batteries, or you need spares, this article will be very useful. New sections in this 2022 article cover advanced camera battery chargers and off-grid power.


1. Batteries


AAA/AA/C/D/9V


Most light painter’s first flashlights/torches are based on AAA, AA, and less commonly C, D, and 9V size batteries. These use non-rechargeable Alkaline, Zinc-chloride (Heavy Duty), Lithium, or rechargeable NiMH batteries. These all have a max voltage of approximately 1.5V, apart from 9V batteries. Compared to li-ion batteries, these are generally very safe, and easy to purchase.


Alkaline batteries generally have good capacity, and are widely available almost everywhere. As they are not rechargeable, they are quite wasteful. Alkaline batteries can also leak, especially if they are left is a discharged state for a long time, which can destroy your flashlight. Heavy Duty (Zinc-chloride) batteries are a cheaper alternative but may only last a few minutes in a good flashlight.


Lithium batteries (such as Energizer Ultimate Lithium) typically last twice as long as good Alkaline or NiMH batteries, but also cost more than twice the price of Alkaline. As they are not rechargeable, I would only really recommend them for use in extreme temperatures (-40C to +60C) or if you no access to a power supply for a while.


For AAA/AA batteries I would recommend using low self discharge (LSD) NiMH batteries. Recommended AAA and AA size NiMH batteries include:

  • Premium quality (high capacity, high number of recharges, very low self discharge)- Ikea Ladda (grey, made in Japan version), Fujitsu Ready To Use, Panasonic Eneloops/Eneloop Pro (made in Japan in versions only).

  • Good quality - GP, Powerex, Panasonic Eneloop (Chinese made version).

Whilst there are plenty of cheaper NiMH AAA/AA batteries, my testing has shown many of them to significantly reduce in capacity after only approximately 10 cycles, so lower purchase cost may not be cost effective in the long run. The above recommendations are based on testing by experts on flashlight forums, and not based on dodgy Amazon reviews or even dodgier Top Ten websites.


For rechargeable C, D, and 9V batteries there are decent options from Varta/Rayovac, GP, and Powerex.

The best value for money NiMH AA and AAA batteries are from Ikea
The best value for money rechargeable NiMH AA and AAA batteries are from Ikea

Button/Coin Batteries


Some very small 'keyring' flashlights, LED glow sticks, and RF remote controls may use lithium or alkaline button/coin batteries. Be extremely careful with button batteries around children, as there have been many cases of permanent injury and death in children who have swallowed them.


CR123


Lithium CR123A (3V) batteries are non-rechargeable, and were popular in the earlier years of LED flashlights. They have a good shelf life and can handle large temperature ranges. Unfortunately, they have been known to explode if two CR123As in series have different voltages. They have largely been superseded by rechargeable Li-ion batteries, and thus I don’t recommend using CR123A batteries.


Li-ion - Overview and Safety


The rest of the battery section of this buying guide will focus on Li-ion batteries, which are pretty much essential if you want to use high brightness flashlights. The vast majority of Li-ion batteries used in flashlights have a max voltage of 4.2V, and a nominal voltage of 3.6/3.7V. I'm not aware of any flashlights that use max 4.35V batteries. Whilst newer IMR and INR Li-ion batteries are more chemically stable than older ICR types, use of Li-ion batteries still requires knowledge of the safety risks required to safely use these batteries.


Key Li-ion safety aspects so as to avoid damaging the battery are as follows:

  • Do not charge above 4.2V. High quality chargers should terminate charge at approx. 4.2V. Be aware that some chargers may have a 4.35V setting/switch, don't use this!

  • Do not discharge below 2.5V. Look for flashlights with low voltage protection, or mechanically lock out the flashlight if possible (usually by unscrewing the tail cap). Beware of parasitic drain depleting batteries in stored lights.

  • Use a charger with voltage readout.

  • For lights that use more than one Li-ion battery in series or parallel, you must use matching batteries and they must always be at the same voltage before use (check using a charger with voltage readout). If voltages are not the same, you risk reverse charging, and a possible explosion!

  • Always insert batteries with the correct polarity. Most flashlights now have reverse polarity detection or prevention.

  • Do not short circuit the battery.

  • Store spare batteries in plastic cases. No one likes battery explosions in their trousers!

  • Do not use damaged Li-ion batteries, this includes damaged wrappers.

  • Do not charge or discharge at currents higher than the battery’s rating.

  • Batteries with added protection circuits will help prevent over charge, over discharge, or over-current. However, protection circuits are an additional point of failure.

  • Always periodically check on the batteries during a charge – do not charge whilst you are asleep or out of the house.

  • For flashlights with internal charging, cease charging as soon as the fully charged indicator light has been activated.

  • Charge, and store batteries and flashlights in non-flammable locations.

  • Keep batteries out of reach of children and people with no common sense.

  • Li-ion batteries will degrade slower if stored closer to 50% capacity (around 3.6-3.7V)

If you were very unfortunate, and a Li-ion battery starts to heat up rapidly (thermal runaway), quickly leave it in as safe a place as possible and keep your distance. The pressure build up during a battery vent will cause an explosion from both ends of the flashlight tube (and side if there is a side button). If there is a source if ignition, there may be flames and resulting fire. Avoid breathing in the fumes, and call the fire brigade immediately.


Li-ion batteries have names that denote the approximate size of that battery in mm. The first two numbers are width, and the second two are length. The most commonly used in flashlights for light painting are 18650, 21700, and 26650 batteries. Unfortunately, that is where the standardization ends, especially when you add protection circuits onto the ends of some batteries, which adds to both the length and width. Not all 18650, 21700,or 26650 batteries will fit in a flashlight (and even some chargers) as they may be too short, too long, or too wide. Some flashlights require button tops, some don’t. Thus it is advised to read reviews, or follow manufacturer recommendations of battery sizes that will fit.


Li-ion - recommendations


Most consumer grade flashlights (such as Nitecore, Fenix, Klarus, Ledlenser, Olight, Acebeam, and Thrunite) are now sold with Li-ion batteries either included or optional. Given the current worldwide shortage of Li-ion batteries, I would always advise purchasing the light with optional batteries. Battery to flashlight compatibility is getting complicated, as some flashlights are only compatible with button top protected batteries, some are only compatible with customised/proprietary batteries (often with +ve and -ve connections at one end), some come with USB charging in the actual battery. Due to this complexity, I now just recommend that users follow the manufacturer's recommendations (even if it is more expensive), and I no longer recommend 3rd party protected batteries for consumer grade lights as there is too high a risk of incompatibility.

Consumer manufacturers are increasingly making Li-ion battery connections proprietary
Consumer manufacturers are increasingly making Li-ion battery connections proprietary

A few flashlights, some headlamps, and almost all LED panel lights are only available with integrated and non-user replaceable batteries. Whilst this is great for ease of use, also means that the light may become a doorstop after around 3 years of heavy use. Li-ion batteries last longer the more that the battery charge sits closer to 50%, so try not to leave lights fully charged or fully discharged.


For the enthusiast flashlight market, the situation is different. High power lights aimed at flashlight enthusiasts (such as Convoy, Noctigon, Emisar, Fireflies, and Lumintop) tend to use unprotected Li-ion batteries. These can sometimes be purchased as an optional extra with the flashlight, but in some cases you may need to purchase the batteries separately. These unprotected Li-ion batteries are all manufactured with a flat top (+ve pole). Unfortunately, unprotected batteries are getting harder and more expensive to purchase - see the next section on where to buy! Some flashlights (notably "soda can" sized) require Li-ion batteries with added button tops. As these batteries are increasingly difficult to find, I no longer recommend these flashlights unless batteries are included.


Best Unprotected 18650 for Good Current (<8-10A) and Maximum Capacity (3200-3600mAh)

  • Panasonic/Sanyo NCR18650GA - most recommended, but limited supply.

  • Molicell M35A.

  • Samsung INR18650-35E3.

  • EVE INR18650/33V.

  • LG MJ1.

Best Unprotected 18650 for High Current (>8A) and Good Capacity (approx. 3000mAh)

  • Sony US18650VTC6 3000mAh 30A.

  • Samsung INR18650-30Q 3000mAh 15A - most popular with flashlight enthusiasts.

  • LG INR18650-HG2 3000mAh 20A.

Best Unprotected 21700:

  • Samsung 50E2/E3 / BAK N21700CG-50 / Molicell M50A – good for 5000mAh capacity and <10A current.

  • Samsung 50S - good for 5000mAh capacity and <15A current, if you can find one!

  • Molicell P45B - excellent for good 4500mAh capacity and high current <20A, successor to the Molicell P42A.

  • Samsung 40T/T3 / LG H40A 30A – excellent for 4000mAh capacity and high current <30A.

Best Unprotected 26650:

  • Keeppower 5500mAh - high quality 26650 with good current and capacity.

18650 and 21700 Li-ion batteries
18650 and 21700 unprotected Li-ion batteries

Where to buy Li-ion batteries


Due to safety reasons, Li-ion shipping is currently problematic. International shipping has become more restricted. Supply chain issues due to COVID-19, plus high demand for Li-ion batteries in consumer products such as eBikes and eScooters have caused severe stock shortages and price increases. Many Li-ion battery manufacturers also do not wish to sell loose batteries to consumers. If Li-ion batteries are not included or optional with a flashlight, I would recommend to purchase from as close to home as possible. Flashlight/torch and vape stores are good places to start, especially for flashlight brand batteries, but can be expensive. Online retailers recommended by members of the BLF flashlight forum include (these are all non-affiliate links):


Tinkertech (Australia) - currently the best prices in Australia.

Ausbatteries (Australia)

Lanplus (Australia)

Techaroundyou (Australia)

Nkon (EU) - most recommended EU retailer.

Akkuteile (EU)

Ecolux (UK)

Fogstar (UK)

18650UK (UK)

18650canada.ca (Canada)

Illumn (USA, also ship to Canada)

Liion Wholesale (USA)

18650 Battery Store (USA)

Orbtronic (USA)

Mountain Electronics (USA)


Li-ion – What To Avoid


Unfortunately, there are still many very bad and dangerous Li-ion batteries available (including from Amazon, eBay, and Chinese electronics retailers), with highly over-exaggerated current and capacity ratings. Any 18650 battery advertised with a capacity over 3600mAh, or 21700 battery with a capacity over 5700mAh, is fake or misleading! Brands to avoid include Ultrafire, GTL, GTF,  GIF, SkyWolfeye, Meco, and Elfeland.


2. Chargers


NiMH Chargers


Most NiMH chargers (including ones for sale at supermarkets) are 'dumb' timer based and can overcook batteries, rapidly shortening their lifespan. Thus it is recommended to only use smart chargers. Good NiMH only smart chargers include:

  • Panasonic BQ-CC65 – advanced 4 bay smart charger.

  • Panasonic BQ-CC63 – 8 bay smart charger.

  • Panasonic BQ-CC55 – best value 4 bay smart charger.

  • XTAR BC4 - 4 bay smart charger with USB-C input. Product link (affiliate).

  • XTAR BC8 - 8 bay smart charger with USB-C QC3 input. Product link (affiliate).

However, unless you are only ever intending on using NiMH batteries, I would highly recommend looking at multi-chemistry chargers (see below) that can charge both NiMH and Li-ion batteries, plus some can also act as powerbanks.


Many multi-chemistry chargers can also charge C and D batteries, but for 9V there are fewer options, with some specialist Maha Powerex models being recommended.


Flashlight Internal Chargers (Li-ion)


Most consumer grade, and some enthusiast grade Li-ion battery flashlights, and almost all LED panel lights, now have internal charging mechanisms, using USB (micro, USB-A, USB-C) or magnetic chargers. In some cases, the charging port is in the battery. As long as you buy from reputable flashlight brands, the quality should be very high (which is a big improvement to when I started writing these buying guides back in 2017). Be aware that some magnetic charging connections need to be kept away from conductive materials such as steel wool so as to avoid a short circuit and resulting fire!


Many flashlights now have internal charging
Many flashlights now have internal charging

Multi-chemistry (NiMH and Li-ion) Chargers


If any of your flashlights do not have internal charging, you want to keep a better eye on your battery voltage, or you need to charge lots of unprotected batteries at the same time, I would highly recommend purchasing dedicated multi chemistry chargers (NiMH and Li-ion). These allow you to monitor battery voltage, or even battery analyzing functionality such as internal resistance, and capacity testing. I generally don't recommend basic Li-ion chargers without voltage display (with 2 exceptions below), or budget analysing chargers with documented QC issues, which is why some popular chargers are not on this list.


Basic Li-ion only Chargers (recommended for travel or backup use only):

  • XTAR ANT MC1 Plus - a single slot, inexpensive, micro USB charger for 14500, 18650, 21700, and 26650 batteries. Protected 21700s will not fit.

  • Nitecore LC10 Portable Magnetic Charger - can charge almost all Li-ion batteries except for proprietary designs, and can also act as a powerbank. Cannot charge NiMH batteries. Product link (USA) (affiliate).

Best NiMH/Li-ion Chargers (voltage display):

  • Nitecore UMS2 – Nitecore’s most advanced 2 slot charger. Product link (USA) (affiliate).

  • Nitecore UMS4 – Nitecore’s most advanced 4 slot charger. Product link (USA) (affiliate).

  • GyrFalcon All-88 – best 8 slot charger.

  • XTAR PB2S - good 2 slot travel charger for 18650 and unprotected 21700 batteries that can also act as a QC3.0 or PD3.0 powerbank. Product link (affiliate).

  • XTAR VC2SL – good 2 slot charger with QC3.0 USB power supply, fits protected 21700s.

  • XTAR X2 Extended Version – high quality 2 slot charger, fits protected 21700s.

  • XTAR X4 Extended Version – high quality 4 slot charger, fits protected 21700s.

Best Analyzing NiMH/Li-ion Chargers (voltage display, internal resistance, and capacity testing):

  • Vapcell S4 Plus – advanced 4 slot analyzing charger, fits protected 21700s. Over-discharged NiMH batteries may need to be "jump started" in NiMH dumb/smart chargers first though. This charger is what I currently use, and is in my opinion the best overall charger. Product link.

  • XTAR VC4SL – Xtar have upgraded the VC4S with longer slots of protected 21700s. This 4 slot analyzing charger, with QC3.0 USB power supply, and automatic current selection is the best consumer grade charger available, though you might need to manually override the automatic current selection. Product link (affiliate).

  • SkyRC MC3000 – most advanced analyzing charger, but for experts/enthusiasts only.


Vapcell S4 Plus is the best value for money charger
The Vapcell S4 Plus is the most recommended analysing charger

The XTAR VC4SL is the best consumer grade analysing charger
The XTAR VC4SL is the best consumer grade analysing charger

Camera Battery Chargers


This is a new section in the 2022 article. For most photographers, the charger that comes with your camera (if it even comes with a charger) will be adequate. However, if you want to charge 2 batteries simultaneously, check battery health, battery voltage, or even have a rough idea of how much longer the batteries have to charge, then Nitecore and Hahnel have an excellent range of advanced camera battery chargers. They are available for various battery types for a range of different camera manufacturers. The Nitecore (affiliate link) models display battery voltage, charging current, charged capacity, battery health, and temperature. Input is either by USB or mains depending on the model. The Hahnel PROCUBE2 models display percentage full, charged capacity, battery health check, has mains or 12V input, 2.4A USB output, and integrated 4xAA charger (though it is unknown if this is a dumb or smart NiMH charger).


Nitecore produce advanced camera battery chargers
Nitecore produce advanced camera battery chargers

Off-grid power


Running a light painting or night photography meetup or workshop in an off-grid location, or whilst camping? Or do you want to run a star tracker for astro-photography in the wilderness? You might need a portable "power station", which is basically a large power bank. These can typically be charged from the mains, car 12V power supply, or solar power. The output options vary between models, but can typically supply 120/240V (with Watt output limitations), USB-A, USB-C, and 12V power. Devices with less than 20Ah are more useful for charging camera, phone, and flashlight batteries multiple times. Devices with more than 20Ah or more can additionally be used to charge laptop or drone batteries multiple times, plus various mains powered devices or even a small smoke machine. However, as even an entry level(ish) 18Wh version can weigh 4kg, then unless you need 120/240V mains power, you might be better off just bringing spare batteries. Recommended manufacturers (of which brand availability varies between countries) include Nitecore (affiliate link), Anker, Jackery, EcoFlow, Dometic, Goal Zero, and XTAR (affiliate link). The Nitecore range has had some good reviews recently from flashlight enthusiasts. Take care when reviewing available inputs, outputs, and power limitations when purchasing.
